Single core cable ARG16M16 1x150 sq. mm aluminum conductor 0.6/1 kV
9X9 ARG16M1X150
Single-core ARG16M16 1x150 sq mm aluminum conductor 0.6/1 kV cable with the following characteristics:
- Conductor diameter: 14.4 mm
- Insulation thickness: 1.4 mm
- Sheath thickness: 1.6 mm
- Max electrical resistance at 20°C: 0.206 ohm/ km
- Current carrying capacity in air: 280A
- Current carrying capacity in buried pipe: 250A
The selling price is per meter.
The producers of our cables are:
- Baldassari cavi
- Icel
- La Triveneta
- Prysmian
The right of withdrawal does not apply to this product as the cables are cut according to your personal specifications.
Single core cable ARG16M16 1x150 sq. mm aluminum conductor 0.6/1 kV
€4.13
€4.13
Tax included
Tax included
Items Available: 3171
: 741
Two-year warranty
Single-core energy cable with aluminum conductor, insulated with high-modulus ethylene propylene rubber of G16 quality, under special thermoplastic sheath of M16 quality, with special fire reaction characteristics and complying with the Construction Products Regulation (CPR).
Features:
- Conductor: rigid aluminum cord, class 2
- Insulation: High-modulus ethylpropylene rubber compound, quality G16
- Sheath color: Green
- Rated voltage Uo/U: 0.6/1 kV
- Maximum operating temperature: 90°C
- Minimum operating temperature: -15°C (in the absence of mechanical stress)
- Minimum installation temperature: 0°C
- Maximum short-circuit temperature: 250°C up to 240 mm² section, over 220°C
- Maximum tensile stress: 50 N/mm2
- Minimum bending radius: 6 times the maximum outer diameter
Conditions of use: For energy transport in industrial and/or residential construction. Particularly suitable in places with fire hazards and high presence of people such as offices, schools, supermarkets, cinemas, theaters, discos. Suitable for use indoors in even wet rooms or outdoors; fixed installation on masonry and metal structures. Also permitted for underground installation.
There are no reviews
Data sheet
- Colour:
- Green
- Diameter:
- 14,4mm
- Type:
- Aluminum cables
- Cross-Section:
- 150mmq
- With yellow/green:
- No
- Number of cables:
- 1
