Lovato modular contactor 20A AC1 2NO 220VAC 1 module CN2020220

Lovato
LOV CN2020220 8013975143759

Lovato modular contactor, with the following characteristics:

  • IEC/EN rated insulation voltage Ui V: 440
  • Rated impulse withstand voltage Uimp: kV 4
  • Rated auxiliary voltage Us: 220 V AC/DC
  • IEC Conventional free air thermal current Ith UN 20
  • Minimum switching capacity: ≥17V ≥50mA
  • Power loss per pole (average value) Ith: w 1.7
  • Type of operating voltage: AC/DC
  • Number of poles: 2
  • Number of DIN modules: 1
  • Fixing: 35mm DIN rail
Do you have questions about this product or did you not find what you were looking for? Ask us!

Lovato modular contactor 20A AC1 2NO 220VAC 1 module CN2020220

€22.98
€22.98

Lovato modular contactor 20A AC1 2NO 220VAC 1 module CN2020220

€22.98
Tax included
Items Available: 150
Further availability of the manufacturer

Lovato modular contactor 20A AC1 2NO 220VAC 1 module CN2020220

€22.98

Buy it within and receive it from Monday, 11 November
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Features:

  • Lovato Series
  • Working temperature: min°C -15/max °C 55
  • Storage temperature: min °C -30/max °C 80
  • Maximum altitude: m 2000
  • Weight: 135 grams
  • Front IP degree: IP20
  • Pollution degree: 3
  • Instrument Terminals: PZ2

Operations:

  • Mechanical life cycles 3000000
  • AC3 Electrical Life cycles 300000
  • Electrical life AC1 cycles 200000

Tightening torque for coil terminal:

  • Max: Nm 0.6
  • Max: Ibin 0.6

Tightening torque for terminals:

  • max : Nm 1.2
  • max : Ibin 0.9

Prezzi competitivi, spedizioni rapide prodotti conformi alla descrizione . Raccomandato

Read all reviews

Data sheet

Type:
Contactors
Voltage:
220VAC
Poles:
2P
Degree of protection:
IP20
Amps:
20A
