Double Insulated Flameproof Cable 3X16mmq 1 Meter Yellow Green FG16OR163G16

Cavi
9X9 FG16R3G16

Double Insulated Flameproof Cable 3X16mmq 1 Meter Yellow Green FG16OR163G16



Diameter: 17.6 mm



Sold by the meter.

The producers of our cables are:

  • Baldassari cavi
  • Icel
  • La Triveneta
  • Prysmian
The delivery of the cable from one manufacturer rather than another is dictated by the availability of the moment. All our cables comply with the relevant legal regulations.
The right of withdrawal does not apply to this product as the cables are cut according to your personal specifications.
Do you have questions about this product or did you not find what you were looking for? Ask us!

Double Insulated Flameproof Cable 3X16mmq 1 Meter Yellow Green FG16OR163G16

€8.36
€8.36

Double Insulated Flameproof Cable 3X16mmq 1 Meter Yellow Green FG16OR163G16

€8.36
Tax included
Items Available: 3842
Further availability of the manufacturer

Double Insulated Flameproof Cable 3X16mmq 1 Meter Yellow Green FG16OR163G16

€8.36

Buy it within and receive it from Monday, 11 November
Two-year warranty
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Reference IEC Guide 20-67 as applicable: FG16OR cable is suitable for power supply in industry, construction sites, residential construction. For indoor and outdoor fixed laying, even in wet environments; for direct and indirect underground laying. For outdoor installation, on masonry and metal structures, on walkways, pipes, ducts and similar systems. Suitable for bundle installations in environments with higher risk in case of fire.



Reference Construction Products Regulation 305/2011 EU and Standard EN 50575: Given the properties of limiting fire development and heat emission, the cable is suitable for power supply in buildings and other civil engineering works.



Description:

  • Conductor: red copper, flexible formation, class 5
  • Insulation: rubber, G16 quality
  • Filler: thermoplastic, penetrating between cores (only in multi-core cables)
  • Sheathing: PVC, R16 quality
  • Color: gray

Functional characteristics:

  • Rated voltage Uo/U: 600/1000 V AC 1500 V DC.
  • Maximum Um voltage: 1200 V ac 1800 V dc also to earth
  • Industrial test voltage: 4000 V
  • Maximum operating temperature: 90°C
  • Minimum operating temperature: -15°C (in the absence of mechanical stress)
  • Maximum short-circuit temperature: 250°C

Good resistance to industrial oils and greases. Good behavior at low temperatures. Resistant to UV radiation



Laying conditions:

  • Minimum laying temperature: 0°C
  • Recommended minimum bending radius: 4 times the cable diameter
  • Maximum recommended tensile stress: 50 N/mm2 of copper cross section

Reactions to Fire: Complies with CPR REGULATION 305/2011/EU:

  • Standard: EN 50575:2014+A1:2016
  • Class: cca-s3, d1, a3
  • Classification: (IEC UNEL 35016) EN 13501-6
  • Heat and smoke emission and flame development EN 50399
  • Non-propagation of flame: EN 60332-1-2
  • Corrosive and halogenated gases: EN 60754-2
  • Notified Body: 0051 - IMQ





There are no reviews

Data sheet

Colour:
Grey
Cross-Section:
16mmq
With yellow/green:
Yes
Number of cables:
3

Cables with the same section
