Abb Circuit breaker S204M 63A 4P 10KA D 4 Modules S602129
ABB S602129
4016779605014
Abb series S204M circuit breaker:
- Rated current 63A
- Poles 4
- Rated short-circuit power 10KA (AC)
- Type D
- 4 Modules
- Rated operating voltage: 400V
Abb Circuit breaker S204M 63A 4P 10KA D 4 Modules S602129
€166.25
€166.25
Tax included
Tax included
Items Available: 10
: 1
Frequently bought together
System pro M compact S200 circuit breakers protect installations from overloads and short circuits, ensuring reliability and safe operations.
All circuit breakers in the S200 range comply with CEI-EN 60898-1, CEI- EN 60947-2 and UL1077 and CSA 22.2 No. 235 (except the 4.5kA version), allowing use in residential, commercial and industrial applications.
Can be associated with DDA 200 series differential blocks.
Curve D, trip threshold from 10 to 29 times In, for application of circuits with high inrush currents (motors, transformers, etc.).
A circuit breaker is a safety device that can automatically (i.e., without external intervention) interrupt the flow of electric current in an electrical circuit in the event of an overcurrent.
Characteristics:
- Reference Standards: IEC/EN 60898-1 - CSA 22.2 No. 235 - IEC/EN 60947-2 - UL 1077
- Tripping characteristic: D
- Rated operating voltage: according to IEC 60898-1 400 V AC - according to IEC 60898-1 400 V - according to IEC 60947-2 440 V AC
- Operating voltage: Maximum (Including Tolerance) 440 V AC - Minimum 12 V AC - Minimum 12 V DC
- Rated insulation voltage (Ui): according to IEC/EN 60664-1 440 V
- Impulse withstand voltage (Uimp): 4 kV at 2000 m 5 kV - at Sea Level 6.2 kV
- Dielectric proof voltage: 50/60 Hz, 1 min: 2 kV
- Input voltage type: AC/DC
- Rated current (In): 63 A
- Rated short-circuit capacity: (AC) 10 kA - (230 V AC) 10 kA - (400 V AC) 10 kA
- Rated extreme short-circuit capacity (Icu): (230 V AC) 25 kA - (400 V AC) 15 kA - (440 V AC) 15 kA - (230 V) 25 kA - (400 V) 15 kA
- Rated conditional short-circuit current (Inc): (230 V) 10 kA - (400 V) 20 kA
- Rated service short-circuit capacity (Ics): (230 V AC) 7.5 kA
- Rated frequency (f): 50 / 60 Hz
- Power loss: 19.2 W at Rated Operating Conditions per pole 4.8 W
- Supply voltage connection: Arbitrary
- Contact position indication: Red ON / Green OFF
- Energy limitation class: 3
- Electrical resistance: 10000 AC cycle(s)
- Mechanical resistance: 20000 cycle(s)
- Number of protected poles: 4
- Number of poles: 4
- Overvoltage category: III
- Tightening torque: 2.8 N-m
- Screw Terminal Type: Failsafe Bi-directional Cylinder-lift Terminal
- Actuator Marking: I / O
- Actuator Material: Insulation Group II, Black, Sealable
- Enclosure Material: Insulation Class II, RAL 7035
- DIN Rail Mounting: TH35-15 (35 x 15 mm Mounting Rail) according to IEC 60715 - TH35-7.5 (35 x 7.5 mm Mounting Rail) according to IEC 60715
- Mounting Position: Any
- Recommended Screwdriver: Pozidriv 2
- Accessories Available: Yes
- Connection Capacity: Busbar 10 / 10 mm² - Flexible with Ferrule 0.75 ... 25 mm² - Flexible 0.75 ... 25 mm² - Flexible 0.75 ... 25 mm² Rigid 0.75 ... 35 mm² - Rigid 0.75 ... 35 mm² - Stranded 0.75 ... 35 mm²
- Installation dimensions: according to DIN 43880 1
- Terminal type: Screw Terminals
- Ambient temperature: In operation -25 ... +55 °C - In storage -40 ... +70 °C
- Ambient air reference temperature: 30 °C
- Degree of protection: IP20
- Width in number of modular intervals: 4.0
- Product width: 70 mm
- Product height: 88 mm
- Product depth: 69 mm
- Product net weight: 0.5 kg
- Pole net weight: 0.125 kg
- Built-in depth (t2): 69 mm.
There are no reviews
Data sheet
- Voltage: 400VAC
- Modules: 4
- Poles: 4P
- Curve: D
- Breaking capacity: 10KA
- Degree of protection: IP20
- Amps: 63A
- Circuit Protections: Circuit breakers
