Advantages:

• Allows adjustment of brightness and ringer volume, which is customizable by choosing from different melodies
• Equipped as standard with 5 sensitive touch buttons with LED backlighting for phonic socket, door opener, auto switch-on, switchboard call, Silent mode and door status indication LED
• Handles out-of-door call as standard
• Possibility of adding 3 additional buttons with accessory art. 6734W
• Complete with a 2 8-position dip-switch for user code and button programming
• Includes wall-mounting bracket or on switch range box and upright branch terminal art. 1214/2C



Features:

• Dimensions: Height (mm) 160 - Width (mm) 115 - Depth (mm) 22
• Product weight (g) 500
• Product color White RAL9003
• Type ABS coating materials
• Wall mounting Yes
• Table base mounting Yes, with dedicated accessory.



Compatible systems:

• Audio/video Simplebus 2 with power supply item no. 4888C
• Audio/video Simplebus 2 with power supply unit art. 1210/1210A




Simplebus 2 audio/video kit with power supply unit art. 1209:



Display:

• Display size (") 4.3
• Aspect ratio 16:9
• Resolution (pixels) 480x272



Audio features:

• 6mm (ø) microphone, Omnidirectional
• Speaker 36mm (ø), 40 Ohm, 1W
• Technologies implemented Full-Duplex



Electrical features:

• Power supply type Power supply from video intercom bus.
• Supply voltage 22÷34 VDC (Bus)
• Stand-by power consumption (W) 0.06
• Maximum power consumption (W) 11.9



Hardware Features:

• Type of buttons Capacitive
• Service buttons Door open, Answer, Silent (Privacy), Door open
• No. of programmable buttons for additional functions 2 (5 with accessory item 6734W)
• Terminals L L CFP1 CFP2
• Removable terminals



Adjustments:

• Speaker volume
• Microphone volume
• Ring volume
• Screen brightness
• Screen contrast
• Screen color



General data:

• IP degree of protection IP30
• Operating temperature (°C) 5 ÷ 40
• Operating humidity (RH max) (%) 25 ÷ 75
• Environmental class I (B1)
• CE Certifications RoHS II - 2011/65/EU (EN IEC 63000:2018), EMC 2014/30/EU (EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011)
• Door opener
• Automatic door opener on call (Doctor)
• Silent Mode (Privacy)
• Auto power on
• Call to switchboard
• Intercom calls
• Out-of-door call input
• Customizable ringtone
• Auto answer (hands-free)
• Sending alarm calls
• Actuator control
• Multiple address
• Door open signaling
