Schneider TeSys Auxiliary Contact Block 1NO+ 1NC Screw Terminals LADS2
SNR LADS2
3389110386103
Schneider TeSys auxiliary contact block with push-button control and thermal protection regulation range, screw terminals with the following characteristics:
- Pole contact composition: 1 NO + 1 NC
- Rated operating voltage: 690V AC
- Conventional thermal current in open air: 10A at <60°C
- Minimum switching current: 5 mA
- Minimum switching voltage: 17V
- IP degree of protection: IP20 according to IEC 60529
- Protection treatment: TH in accordance with IEC 60068
Schneider TeSys Auxiliary Contact Block 1NO+ 1NC Screw Terminals LADS2
€63.30
€63.30
Tax included
Tax included
Items Available: 2
Frequently bought together
LADS2 is a timed auxiliary contact block from Schneider Electric for TeSys D and TeSys F contactors. A front-mount block, it features 1NO+1NC contacts up to 10 A 690 V AC, with an excitation delay setting range of 1 to 30s. Easy front-mount installation via clip, ensures high reliability and durability. Available worldwide, has certification to various standards (IEC, UL, CSA, CCC, EAC, for use in marine environments) and is Green Premium (RoHS/REACH) compliant.
Advantages:
- Additional block with mechanically connected 1NA+1NC auxiliary contacts, with delayed operation.
- High electrical durability: several million operating cycles in AC-14/AC-15/DC-13 depending on conditions.
- Clip-on front mounting on all TeSys D and TeSys F contactors.
- Excitation delay setting range of 1 to 30s
Features:
- Rated operating current: 6 A AC-15 at 690 V - 1.04 A DC-13 at 125 V - 0.55 A DC-13 at 600 V
- Rated insulation voltage: 690 V according to IEC 60947-5-1 - 600 V according to UL 60947-5-1 - 600 V according to CSA C22.2 No 60947-5-1
- Rated closing power Irms: 140 A at <= 690 V "AC" according to IEC 60947-5-1 - 250 A at <= 690 V DC according to IEC 60947-5-1
- Allowable temporary rated current: 100 A at <60 °C 1 s - 120 A at <60 °C 500 ms - 140 A at <60 °C 100 ms
- Mechanical life span: 5 Mccycles
- Non-overlapping time: 1.5 ms to deactivation without overlap between NC and NO contacts - 1.5 ms to activation without overlap between NC and NO contacts
- Terminal connections: Screw fixing terminals 1 cable 12.5 mm² flexible with cable termination
- Screw fastening terminals 1 cables 12.5 mm² flexible without cable termination
- Screw clamps 2 cables 12.5 mm² flexible with cable termination
- Screw clamps 2 cables 12.5 mm² flexible without cable termination
- Screw fastening terminals 1 cable 12.5 mm² rigid
- Screw clamps 2 cables 12.5 mm² rigid
- Screw fixing terminals
- Storage temperature: -60/+80°C
- Operating ambient temperature: -40/+70°C
- Dimensions: height 48 mm - width 44 mm depth 61 mm
There are no reviews
Data sheet
- Type: Auxiliary Contacts
- Voltage: 690V
