Flexible energy cable FTG18OM16 12G 1.5 0.6/1 kV blue

Cavi
9X9 FTG18OM12G1,5

Flexible power cable FTG18OM16 with the following characteristics:



  • Type 12G 1.5 sq. mm
  • Insulation thickness: 1 mm
  • Sheath thickness: 1.8 mm
  • Outer diameter: 20.4 mm
  • Max electrical resistance at 20°C: 13.40 ohm/km



Flexible fire-resistant energy cable, insulated with G18-quality rubber,under M16-quality special thermoplastic sheath, halogen-free, fire-propagating and low smoke development.



The selling price is intended per meter.

Do you have questions about this product or did you not find what you were looking for? Ask us!

Flexible energy cable FTG18OM16 12G 1.5 0.6/1 kV blue

€8.48
€8.48

Flexible energy cable FTG18OM16 12G 1.5 0.6/1 kV blue

€8.48
Tax included
Items Available: 1237
Further availability of the manufacturer

Flexible energy cable FTG18OM16 12G 1.5 0.6/1 kV blue

€8.48

Buy it within and receive it from Monday, 11 November
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Features:

  • Conductor: red copper, flexible formation, class 5
  • Taping: helically wound glass/mica tape
  • Insulation: rubber, G18 quality
  • Filler: thermoplastic LS0H, penetrating between cores, forming sheathing
  • Sheathing: thermoplastic LS0H, M16 quality
  • Color: blue
  • Rated voltage Uo/U: 0.6/1 kV
  • Maximum operating temperature: 90°C
  • Minimum operating temperature: -15°C (in the absence of mechanical stress)
  • Maximum short-circuit temperature: 250°C
  • Minimum installation temperature: 0°C
  • Recommended minimum bending radius: 14 times the cable diameter
  • Maximum recommended tensile stress: 50 N/mm2 of copper cross section
  • Good resistance to industrial oils and greases
  • Good behavior at low temperatures



Use and type of laying: Suitable for carrying power and transmitting signals and commands for electrical systems when maximum safety against fire is required, such as emergency and alarm lights, automatic fire detection, fire extinguishing devices, automatic door openers, ventilation and air conditioning systems, emergency telephone systems. For fixed installation indoors in even wet environments and outdoors. Can be installed on masonry and metal structures, walkways, pipes, ducts and similar systems. Allowed for underground installation, even unprotected.

There are no reviews

Data sheet

Colour:
Blue
Type:
FTG18OM16
Cross-Section:
1.5mmq
With yellow/green:
No
Number of cables:
12

Cables with the same section
