Vimar Elvox Videointercom TAB 7 2-Wire hands-free video door-phone white 40505


VIW 40505 8013406300508

Vimar TAB 7 video door-phone for wall mounting for Due Fili Plus system with 7-in LCD colour display, capacitive keyboard for video door-phone functions and intercom calls, teleloop for hearing aids, bracket for mounting on rectangular or round box, white.

Do you have questions about this product or did you not find what you were looking for? Ask us!
Vimar Elvox Videointercom TAB 7 2-Wire hands-free video door-phone white 40505
€304.34
€304.34

€304.34
Tax included

€304.34

Buy it within and receive it from Friday, 7 March
Two-year warranty
Easy return within 14 days

Tab 7 wall-mounted video door-phone for Due Fili Plus system with 7" LCD colour display, loudspeaker for call signalling, capacitive keyboard for door phone functions (lock release, auto switch-on, auxiliary services, volume, brightness and contrast adjustments and intercom calls.

Features:

  • Mounting: wall-mounted, with metal bracket, on box: circular 2M (Vimar V71701), 3M (Vimar V71303, V71703) horizontal and vertical, 4+4M (Vimar V71318, V71718) and square British standard
  • LCD display 7" 16:9, resolution 800x480 pixel
  • Minimum video signal level on the receiving bus: -20 dBm
  • Capacitive touch keyboard with backlit symbols
  • Power supply from BUS terminals 1, 2 - nominal voltage 28Vdc
  • Absorption: - in standby: 25 mA - maximum current: 350 mA
  • Environmental class: Class A1 (indoor use)
  • Degree of protection IP30
  • Operating temperature: -5 °C - +40 °C (indoor use)
  • Electronic ringer with melody diversification (10)
  • Door call input
  • Dimensions: 165.8 x 184 x 24.2 mm
  • Dip switch for line impedance termination.

Data sheet

Type:
Video Intercoms
Model:
Intercom function
Tloop function
System:
2-Wire
