Vortice Axial fan PUNTO EVO 100 11260
VOR 0000011260
8010300112602
Air and odor Axial fan Vortice model ME 100/4" LL, Wall application, Nominal diameter 100 mm.
Vortice Axial fan PUNTO EVO 100 11260
€78.18
€78.18
Tax included
Tax included
Items Available: 9
: 1
Frequently bought together
Features:
- White plastic resin construction resistant to ageing due to sun exposure ("UV resistant")
- Rated diameter 100 mm
- Thermally protected motor, with shaft mounted on ball bearing supports; 2 operating speeds controlled by an electronic card
- Flow rate between 65 m3/h and 95 m3/h
- Equipped with non-return valve to prevent unintended return of air when switched off
- IMQ certified safety and performance.
Technical specifications:
- Max. current consumption at max. speed (A) 0.052
- Max. current consumption at min. speed (A) 0.039
- Rated Duct Diameter (mm) 100
- Frequency (Hz) 50
- IP 45 degree of protection
- Insulation Class II
- Weight (Kg) 0,6
- Max. power consumption at max speed (W) 9
- Max. power consumption at min. speed (W) 5
- Max. ambient temp. continuous operation (°C) 50
- Voltage (V) 220-240
- Max. flow rate at max. speed (l/s) 26.4
- Max. flow rate at max. speed (m³/h) 95
- Max. flow rate at min. speed (l/s) 18.1
- Max. flow rate at min. speed (m³/h) 65
- Sound power Lw [dB(A)] - max vel 47.4
- Sound power Lw [dB(A)] - min vel 41.3
- Max pressure at max speed (mmH2O) 4.7
- Max pressure at max speed (Pa) 46.09
- Max pressure at min speed (mmH2O) 2.5
- Max. pressure at min. speed (Pa) 24,52
- Sound pressure Lp in free field [dB(A)] 3 m max speed 26,9
- Sound pressure Lp in free field [dB(A)] 3 m min. speed 20.8
- RPM max 2240
- RPM min 1700
La livraison était rapide, la description exacte. Merci
L'aspiratore verrà montato nei prossimi giorni!
ottima &veloce
Data sheet
- Diameter:
- 100
- Type:
- Axial fans
