Palazzoli CEE Interlocked Industrial Socket 2P+E 32A 230V IP67 fuse

Palazzoli
PAL 490226 8014950037308

Palazzoli CEE Interlocked Industrial Socket, with the following characteristics:

  • Rated voltage: 230V
  • Rated insulation voltage: 690V
  • 2 poles+T
  • Rated current 32A
  • Frequency 50/60Hz
  • Degree of protection IP66/IP67
  • With fuse holder base for panel installation
Do you have questions about this product or did you not find what you were looking for? Ask us!
Palazzoli CEE Interlocked Industrial Socket 2P+E 32A 230V IP67 fuse
€80.67
€80.67

€80.67
Tax included
Items Available: 13
Further availability of the manufacturer
€80.67

Buy it within and receive it from Friday, 7 March
Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Frequently bought together

Features:

  • Palazzoli Series
  • Storage ambient temperature: MIN -30°C - MAX +70°C
  • Ambient temperature: MIN -25°C - MAX +50°C
  • Terminal type: indirect clamping
  • Max conductor section 10 mm²
  • Protection: fuses
  • Utilization category AC-23A / AC-3 32A - 250V
  • Shock resistance IK08 according to IEC/EN 62262
  • Color: gray RAL 7035
  • Hourly ref: 6h
  • Body material: thermoplastic
  • Execution: panel
  • Insulation class II
  • Width 108 mm
  • Dimensions 103X230X135 mm

There are no reviews

Data sheet

Type:
Interlocked switch socket outlets
Voltage:
220/250VAC
Poles:
2P+E
Degree of protection:
IP67
Installation:
Wall/Recessed
Amps:
32A
