LEF 12-24-48Vdc IP20 LECV1248TF dimmer interface repeater

Lef
LEF LECV1248TF 8054521539275

Repeater for LEF LED dimming interface with Phase Cut (TF) control with the following characteristics:

  • Input voltage: 12-24-48Vdc
  • Output voltage: 12-24-48Vdc
  • Output current 12-24-48 Vdc: 10A
  • Output power 12-24-48 Vdc: 120-240-480W
  • Brightness controller for LED modules 12-24-48Vdc
  • Phase-cut brightness control with modes: TRIAC Leading-Edge - IGBT Trailing-Edge
  • PWM output voltage frequency: 244Hz - 2000Hz (2KHz)
  • Degree of protection: IP20
  • dimmable
    • Do you have questions about this product or did you not find what you were looking for? Ask us!

    LEF 12-24-48Vdc IP20 LECV1248TF dimmer interface repeater

    €39.65
    €39.65

    LEF 12-24-48Vdc IP20 LECV1248TF dimmer interface repeater

    €39.65
    Tax included
    Items Available: 1
    Further availability of the manufacturer

    LEF 12-24-48Vdc IP20 LECV1248TF dimmer interface repeater

    €39.65

    Buy it within and receive it from Wednesday, 13 November
    Two-year warranty
    Easy return within 14 days
    Purchase with tax breaks

    Are you a professional ?

    Request access to

    Trustpilot

    Features:

    • Plastic container
    • Device for independent use
    • Electrical protection class II
    • Degree of protection IP20
    • Possibility of adapting the dimming range to the DIMMER used (settable by jumper)
    • Open circuit protection (OCP)
    • Overtemperature protection (OTP)
    • Short circuit protection (SCP)
    • Ambient operating temperature Ta -25°C ÷ +50°C
    • Maximum temperature at point Tc 70°C

    There are no reviews

    Data sheet

    Type:
    Dimmer
    Voltage:
    12-24-48V
    Degree of protection:
    IP20
    Installation:
    External
