BM lugs for uninsulated aluminum conductors DIN 120-12 76120
BMM 76120
BM cable lugs for non-insulated aluminum conductors DIN 120-12 with the following characteristics:
- Non-compact circular or sectional conductor cross-section: 120 mm²
- Circular compact conductor section: 150 mm²
- Screw diameter: 12 mm
- Stud size for screw: 1/2"
- Matrix hexagon number 22mm
- Material: aluminum 1050 A EN573-3 with purity not less than 99.5%
The conductor housing is filled with grease (drop point at 90°C) and closed with plastic cap to prevent oxidation.
BM lugs for uninsulated aluminum conductors DIN 120-12 76120
€6.56
€6.56
Tax included
Tax included
Items Available: 53
: 34
There are no reviews
Data sheet
- Diameter:
- 12mm
- Type:
- Terminal lugs
