8GE+2SFP IP-Com PoE 8 Port 10/100/1000 Mbps Cloud Switch G3310P-8-150W
67V G3310P-8-150W
6932392835165
Tenda Cloud PoE Switch 8 Ports Gigabit PoE + 2 SFP, advanced cloud solution designed to provide connectivity, PoE power and remote management via ProFi Cloud and ProFi app. Ideal for video surveillance and wireless networks in SMEs, schools, hotels and parks, with the following features:
-
8 Gigabit PoE ports: Power and data over a single cable, up to 30 W per port
-
Total PoE power: 130 W to power devices such as IP cameras and access points
-
2 SFP uplink ports: Ideal for long-distance connections and cascading links
-
ProFi cloud management: Simplified remote configuration and maintenance
-
Advanced features: VLAN, QoS, link aggregation, DHCP Snooping and MAC address association
-
MAC address table: 8K with automatic learning
-
Power capacity: Up to 250 meters for remote devices
€121.00
€121.00
Tax included
Tax included
Items Available: 5
: 3
8GE+2SFP IP-Com PoE 8-port 10/100/1000 Mbps Cloud Switch
G3310P-8-150W is an intelligent PoE switch for cloud management designed by IP-COM. It provides 8 gigabit PoE ports and 2 SFP ports, can intelligently identify powered devices. The maximum output power of a single port is 30 W and the power of the whole switch is 150 W. It supports IMS Cloud, Web UI and IP-COM IMS app management, making network maintenance more efficient, after-sales costs lower, and management and configuration easier.
Intuitive cloud management
The switch is manageable via ProFi Cloud and ProFi app, enabling remote configurations, monitoring and maintenance. Devices can be added in batches via QR code, streamlining network deployment and reducing operational costs.
Advanced networking features
The G3310P-8-150W switch includes advanced Layer 2 management features:
-
QVLAN: Isolation of networks for enhanced security
-
Link aggregation: Increases bandwidth for critical connections
-
QoS: Prioritizes traffic for sensitive applications such as VoIP and video
-
MAC association: Greater control over network access
Hardware Specifications
| Feature | Detail |
|---|---|
| LED Indicators | 1 Link/Ack LED indicator for each port 1 PoE Max LED indicator for each device 1 Power LED indicator for each device 1 SYS LED indicator for each device |
| Ports | 8 Ethernet 10/100/1000 Base-T ports (data/power) 2 SFP 100/1000 Base-X ports |
| Port lightning protection | 6KV |
| Switching capacity | 20 Gbps |
| Packet forwarding rate | 14.9 Mpps |
| MAC address table | 8K |
| Input voltage | 100-240 V - 50/60 Hz |
| Dimensions | 294x179.6x44 mm (W-D-A) |
| Power consumption of the entire switch | < 150 W |
| Maximum PoE output power | 130 W |
| Operating temperature | 0/+45 degrees |
| Storage temperature | -40/+70 degrees |
| Operating humidity | 10/90% RH, non-condensing |
| Storage humidity | 5/90% RH, non-condensing |
Software specifications
| Feature | Detail |
|---|---|
| PoE Power Management | Port PoE configuration and supported power priority configuration Supported PoE over-temperature protection Intelligent graphical management and detection of supported PoE powered devices |
| Security features | MAC address association supported |
| Port update | HTTP update supported Configuration import and export supported |
| Port update | HTTP update supported Import and export of configuration supported |
| Cloud Management | Supports configuration deployment from IMS cloud platform Supports log reporting and error detection Supports remote maintenance: reboot, backup, update |
| Local display management | Supports router, switch, AP, IP camera detection Supports automatic topology generation Supports online/offline status detection for devices Supports remote IP camera reboot |
There are no reviews
Data sheet
- Type: Network Switch
- System: IP
- Doors: 8+2
