Tenda 5-port Gigabit 10/100/1000 Mbps Ethernet Switch SG105M
67V SG105M
6932849436389
Compact, high-performance Tenda Ethernet switch with 5 Gigabit Ethernet ports for reliable and fast connection. With an ultra-compact design and plug-and-play functionality, it is ideal for home and small business environments that need a stable and scalable network, with the following features:
-
5 Gigabit Ethernet ports: Speeds up to 10/100/1000 Mbps per port
-
Full duplex transmission: Up to 2000 Mbps for high-performance connections
-
Compatibility: MDI/MDIX auto-flip on each port
-
Mounting: Wall and desktop mount
-
Operation: Plug-and-play, no configuration required
€13.53
€13.53
Tax included
Tax included
Items Available: 107
: 30
Tenda 5-port 10/100/1000 Mbps Gigabit Ethernet Switch
With its 2000 Mbps throughput in full duplex mode, the SG105M switch offers high bandwidth, eliminating packet loss and latency issues, which are particularly useful in applications such as HD video surveillance and video streaming.
Ultra-compact design
With dimensions smaller than a credit card, the SG105M is extremely discreet and easy to place. It can be mounted on a wall or placed on a desk to fit perfectly in any environment.
Plug-and-Play
Installation is instant: plug in the network cable, turn on the switch, and you're up and running. MDI/MDIX auto-flip technology automatically detects the connection type, eliminating the need for manual configurations.
Hardware
| Feature | Detail |
|---|---|
| LED Indicator | One Link/Act LED indicator for each Gigabit port One Power LED indicator for each device |
| Interfaces | 5 10/100/1000Base-T Ethernet ports |
| Media transmission | Ethernet: CAT3 UTP or better, Fast Ethernet: CAT5 UTP or better, Gigabit Ethernet: CAT5e UTP or better |
| Size | 82x52x22 mm (W-D-A) |
| Material | Plastic |
| Change Port | 10 Gbps |
| Packet forwarding speed | 7.44 Mpps |
| Bumpers | 1 Mb |
| MAC address table | 2K |
| Input | 100-240 VAC 50/60 Hz |
| Output | 5.0 V 0.6 A (external power adapter) |
| Maximum power consumption | <1,7 W |
| Mounting | Desktop, Wall, Rack |
| Operating Temperature | 0/+45 degrees |
| Storage temperature | -40/+70 degrees |
| Operating humidity | (10% - 90%) RH, non-condensing |
| Storage humidity | (5% - 90%) RH, non-condensing |
Software
| Feature | Detail |
|---|---|
| MAC address learning | Auto-learning and auto-updating |
| Functions | Plug-and-play |
There are no reviews
Data sheet
- Type: Network Switch
- System: IP
- Doors: Five
