Best seller

Olimpia Splendid Unico Evo Air conditioner Wifi Inverter 20 HP PVAN

Olimpia Splendid
SPL 02453 8021183024531

Inverter Air Conditioner without Outdoor Unit Olimpia Splendid UNICO Evo 20 HP PVAN Uses R290 refrigerant, HP model with Heat Pump:



  • Cooling power (min/max) KW 1.0/2.3
  • Heating capacity (min/max) 1.0/2.2
  • Rated cooling capacity Pnominal kW 1.7
  • Nominal heating capacity Pnominal kW 1.5
  • Energy efficiency class A+/A
  • 1 Remote control included
  • wifi
  • taga+v
  • tagah
For a room of approximately 27m²
Do you have questions about this product or did you not find what you were looking for? Ask us!

Olimpia Splendid Unico Evo Air conditioner Wifi Inverter 20 HP PVAN

€1,777.15
€1,723.84
€1,723.84

Olimpia Splendid Unico Evo Air conditioner Wifi Inverter 20 HP PVAN

Lowest price in 30 days:
€1,777.15
Save 3%
€1,723.84
Tax included
Free Shipping
Items Available: 4
Further availability of the manufacturer

Olimpia Splendid Unico Evo Air conditioner Wifi Inverter 20 HP PVAN

€1,723.84

Two-year warranty
Easy return within 14 days
Purchase with tax breaks

Are you a professional ?

Request access to

Trustpilot

Air conditioners of the same series

The quietest and most efficient, with inverter motor and R290 gas with the following advantages:

  • Silent Mode: With the Silent Mode function active (compressor on), it reaches a maximum of 30 dB(A).
  • Sync Power System: The new Twin Rotary compressor and state-of-the-art electronics are synchronized to achieve the best acoustic comfort, at any operating condition
  • High Efficiency: Thanks to the new compressor and optimization of all components, Unico Evo goes up to energy class A+, in cooling
  • R290 Natural Refrigerant gas
  • Remote control included
  • Integrated Wifi
  • Condensate drain: Mandatory (except when "COLD ONLY" mode is set during installation).


Overview:

  • Optimized internal machine layout for easy maintenance
  • Wide flap for even air diffusion in the room
  • Equipped with multi-filter system, consisting of electrostatic filter (with anti-dust function) and activated carbon filter (effective against odors)
  • Backlit display with on-board touch controls
  • On/off contact for enable or energy boost
  • There is an RS485 port set up to control the air conditioner with external BMS in Modbus RTU language
  • Packaging 100% recyclable, 98% plastic free.


Functions:

  • Cooling, heating, dehumidification and ventilation
  • Economy function: saves energy by automatically optimizing machine performance
  • Auto function: modulates operating parameters in relation to room temperature
  • Silent Mode function: mode that sets the machine to the lowest noise level. The compressor and fans are set to bring the sound pressure to only 30 dB(A)
  • 24h timer


Technical data:

  • Cooling output (min/max) kW 1.0 / 2.3
  • Heating capacity (min/max) kW 1.0 / 2.2
  • Rated cooling capacity Pnominal kW 1.7
  • Rated heating capacity Pnominal kW 1.5
  • Rated power input for cooling PEER kW 0.5
  • Rated power consumption for cooling 4.7A
  • Rated power input for heating PCOP kW 0.4
  • Rated power consumption for heating 3.4A
  • Rated energy efficiency ratio EERd 3.1
  • Rated coefficient of efficiency COPd 3.4
  • Energy efficiency class in cooling A+
  • Energy efficiency class in heating A
  • Power consumption in "thermostat off" mode PTO W 14
  • Power consumption in "standby" mode (EN 62301) PSB W 0.5
  • Energy consumption for dual duct equipment - cooling QDD kWh/h 0.5
  • Energy consumption for double duct equipment - heating QDD kWh/h 0.4
  • Cooling power with Silent Mode function kW 1.4
  • Heating power with Silent Mode function kW 1.4
  • Supply voltage V-F-Hz 230-1-50
  • Supply voltage (min/max) V 198 / 264
  • Power consumption in cooling mode (min/max) kW 0.3 / 1.0
  • Power consumption in cooling mode (min/max) A 2.5 / 7.0
  • Power consumption in heating mode (min/max) kW 0.3 / 1.0
  • Absorption in heating mode (min/max) A 2.1 /5.7
  • Dehumidification capacity l/h 0.7
  • Room air flow rate in cooling mode (max/med/min) m³/h 380/270/195
  • Room air flow rate in heating (max/med/min) m³/h 380/270/195
  • Outdoor air flow rate in cooling (max/min) m³/h 650/350
  • Outdoor air flow rate in heating (max/min) m³/h 650/350
  • Number of indoor ventilation speed 3
  • Number of outdoor ventilation speed 6
  • Wall hole diameter mm 162/202 ( Machine supplied with grilles for wall holes 202 mm. If necessary to replace an old Unico, the machine can also be installed with 162 mm diameter holes)
  • Maximum remote control range (distance/angle) m / ° 8 / ±80°
  • Dimensions (Larg. x H x D) (without packaging) mm 1015 x 540 x 180
  • Dimensions (W x H x D) (with packaging) mm 1100 x 605 x 290
  • Weight (without packing) kg 41
  • Weight (with packing) kg 43
  • Indoor sound pressure (Min/Max) dB(A) 26-40 (Statement of test data in semi-anechoic room at 2m distance, minimum pressure in ventilation only)
  • Silent Mode sound pressure level dB(A) 30
  • Degree of protection of enclosures IP20
  • Refrigerant gas Type R290
  • Refrigerant gas charge kg 0.145
  • Global warming potential GWP 3
  • Max operating pressure MPa 3.1
  • Power supply cable (No. of poles x cross-section mmq) 3 x 1.5


Limiting operating conditions (Indoor ambient temperature):

  • Maximum operating temperatures in cooling DB 35°C - WB 24°C
  • Minimum operating temperatures in cooling DB 18°C
  • Maximum operating temperatures in heating DB 27°C

Limiting operating conditions (Outdoor ambient temperature):

  • Maximum operating temperatures in cooling DB 43°C - WB 32°C
  • Maximum operating temperatures in heating DB 24°C - WB 18°C
  • Minimum operating temperatures in heating DB -15°C

Bonjour matériel, fonctionne parfaitement

super produit rien à dire je suis très satisfait

Read all reviews

Data sheet

Air conditioners:
Without outdoor unit
Gas:
R290
Power:
9000 BTU (2,5 Kw)
WIFI:
Integrated
Room Size:
27m²
Energy class:
A+
Series:
Unico
