Haier N1PL-1M6K 6KW Single-phase Hybrid Inverter 85013005A
HAI 85013005A
Haier N1PL-1M6K hybrid inverter, for low-voltage battery:
- Rated output power 6KW
- Power supply single-phase 1 / N / PE, 220 V / 230 V
- Number MPPT 2
- Maximum number of strings per MPPT 1
- Communication RS485, CAN, DRM
Inverter compatible with NLW-1Y5 batteries.
Advantages:
- Maximum bill savings: Possibility of multiple settings in charging and discharging
- Supports a ratio of DC:AC up to 1.5 to connect more PV power
- Built-in EPS Backup swtich time < 10ms
- Complete with all accessories Wifi dongle - TA (max 90A)
- Warranty 5 years Issued by Haier A/C (Italy) Trading S.p.A. Unipersonale
Haier N1PL-1M6K 6KW Single-phase Hybrid Inverter 85013005A
€1,467.10
€1,467.10
Tax included
Tax included
Pay in installments with Klarna
Items Available: 1
Frequently bought together
Features:
DC input (PV side):
- Maximum recommended PV power 7 kW
- Maximum absolute voltage 550 V
- Rated voltage 360 V
- Starting voltage 125 V
- MPPT voltage range 125-500 V
- Maximum input current 14 A / 14 A
- Maximum short-circuit current 17.5 A / 17.5 A
- MPPT number 2
- Maximum number of strings for MPPT 1
AC output (Grid side):
- Rated output power 6 kW
- Maximum apparent output power 6 kVA
- Rated grid voltage 1 / N / PE, 220 V / 230 V
- Rated grid frequency 50 Hz / 60 Hz
- Rated output current 26A
- Power factor 0.9 leading - 0.9 lagging
- THDi <2%.
AC input (Mains side):
- Rated input voltage 176 - 270 V
- Maximum current 26A
- Rated frequency 45 - 55 Hz / 55 - 65 Hz
AC output (EPS):
- Rated output power 6 kW
- Maximum apparent output power 6.6 kVA, 30 sec
- Backup switching time <10 ms
- Rated output voltage 1 / N / PE, 220 V / 230 V
- Rated frequency 50 Hz / 60 Hz
- Rated output current 26A
- THDv (@linear load) <2%
Efficiency:
- Maximum efficiency > 97.6 %
- EU efficiency > 97.0 %
Protections:
- Over/undervoltage protection Yes
- DC insulation protection Yes
- Ground fault protection monitoring Yes
- Grid protection Si
- DC injection monitoring Si
- Return current monitoring Si
- Residual current detection Yes
- Anti-island protection Yes
- Overload protection Yes
- Overheat protection Yes
- Maximum fault current output 55 A
- Maximum in output current 58.7 A
General Data:
- Dimensions (WxDxH) 550 x 520 x 200 mm
- Weight 25 kg
- Transformerless topology
- Operating environment temperature range -25 ~ +60°C
- Degree of protection IP65
- Cooling method Natural convection
- Maximum operating altitude 2000 m
- Grid connection standard G98/G99, IEC 0-21
- Safety/EMC standards IEC/EN 62109-1/-2, IEC/EN 62477-1, EN 61000-6-1/-3
Features:
- LCD screen
- Communication RS485, CAN, DRM; Optional: Wi-Fi, GPRS
- Accessories supplied as standard Wifi dongle + TA (max 90A)
Data sheet
- Type:
- Inverter
- Power:
- 6 to 10KW
- Degree of protection:
- IP65
- Model:
- Hybrids
- MPPT:
- 2
- Connection:
- Single-phase
