Haier Photovoltaic Battery Kit 5NLW-1Y5K 5 kWh 85003001A
HAI 85003001A
Residential ESS low voltage battery kit for Haier 5NLW-1Y5K photovoltaic, Rated energy 5kWh, Rated voltage 51.2 V.
Compatible with N1PL-1M3/3.6/5/6K hybrid inverters.
Haier Photovoltaic Battery Kit 5NLW-1Y5K 5 kWh 85003001A
€2,334.26
€2,334.26
Tax included
Tax included
Pay in installments with Klarna
Items Available: 1
Frequently bought together
Strengths:
- Flexible scalability: Modular design, scalable from 5 kWh to 15 kWh
- Flexible and super slim design Wall or floor mounting; 14cm deep, 50% finer; 45kg weight, 10% lighter than the market
- Easy installation: plug and play
- Extremely safe IP65, can also be installed outdoors
- 6 protection functions For complete safety of battery and system
- Affordable Excellent value for money
- Complete with all accessories
- Harsh climates Charging range between -20°C~50°C
- Warranty 10 years Issued by Haier A/C (Italy) Trading S.p.A. Unipersonal
Features:
- Number of battery modules (in parallel) 1
- Rated energy 1
- Rated system charging power 2.6 kW
- Nominal system discharge power 5.1 kW
- Nominal charging/discharging current 50 A
- Maximum charging/discharging current 100 A
- Rated voltage 51.2 V
- Operating voltage range 43.2 V ~ 57.6 V
- RS485 / CAN / WiFi communication
- Protection function Charging overvoltage, discharging undervoltage, overcurrent, overtemperature, short circuit protection, etc.
- Duty cycle >6000 cycles (25°C)
- Recommended Scalability 3 (Maximum 3 in parallel)
- Degree of protection IP65
- Working temperature Loading -10°C~50°C - Discharging -20°C~50°C
- Working environment humidity 95% (RH)
- Working altitude <2000 m
- Certifications CE, IEC62619, IEC/EN 61000-6-1/3, UN38.3
- Dimensions (WxDxH) 420 x 140 x 650 mm
- Weight 45 kg
Accessories supplied as standard:
- Communication cable 1 x 500 mm RJ45 (communication cascade cable)
- Grounding cable 1 x 1000 mm 10 AWG
- Power cable 2 x 2000 mm (4 AWG, peak current capacity 120A, constant current 100A)
- Communication cable 1 x 3000 mm RJ45 (connect battery to PCS communication)
Data sheet
- Type:
- Storage batteries
- Power:
- 1 to 5KW
