Schneider PrismaSeT Cassette G L600mm H850mm 15M LVS08304
SNR LVS08304
3606481876522
Schneider PrismaSeT G L600mm H850mm 15M IP55 socket-less box with the following features:
- Product range: PrismaSet G
- Device application: low-voltage electrical distribution
- Description of enclosure/cabinet: Floor standing cabinet - width 600mm
- Can be combined side by side
- Number of vertical modules (50 mm): 15
- Number of 18mm modules per row: 24
- Degree of protection: IP55
- Rated insulation voltage: 1000V on the rear main busbars according to IEC 61439-2
- Rated current: 630A at 40°C in accordance with IEC 61439-2
- Short-circuit current: 50 kA
- Rated short-time withstand current: 25 kA 1 s complying with IEC 61439-1
- Rated peak withstand current: 53 kA complying with IEC 61439-1
Schneider PrismaSeT Cassette G L600mm H850mm 15M LVS08304
€531.50
€531.50
Tax included
Tax included
Items Available: 5
Specifications:
- Housing type: Functional enclosure delivered as a kit
- Weatherproofenclosure
- Indoorenclosure
- Metalcasing
Kit composition:
- Uprights
- Back plate
- 2 side panels
- Upper plate
- Bottom plate
- 4 mounting brackets
Features:
- Electrical insulation class: Class I
- Material: treated sheet steel
- Protective treatment: Electrophoresis treatment and heat-cured polyester epoxy powder
- Surface finish: Matt textured
- Dimensions and weight: height 850 mm with plinth - width 575 mm - depth 260 mm - weight: 18.38 kg
There are no reviews
Data sheet
- Type:
- Mailbox
- Modules:
- 15
- Degree of protection:
- IP55
