Siemens Manual call point FDM231-RP FDnet/C-NET S54311-F11-A1


SIE S54311-F11-A1

Manual call point with direct activation and two-wire system for all Siemens FDM231-RP cable types, operates via FDnet/C-NET bus with the following features:



  • Two-color LED indicator for alarm and test
  • Fully resettable via key
  • Built-in line separator
  • Operating voltage: 12-33 V DC
  • Operating current: 180 µA
  • Degree of protection: IP44
  • Activation type: Type A (direct activation)



Ideal for immediate manual activation of an indoor fire alarm.

Do you have questions about this product or did you not find what you were looking for? Ask us!

Siemens Manual call point FDM231-RP FDnet/C-NET S54311-F11-A1

€51.24
€51.24

Siemens Manual call point FDM231-RP FDnet/C-NET S54311-F11-A1

€51.24
Tax included

Out of stock
Incoming

Siemens Manual call point FDM231-RP FDnet/C-NET S54311-F11-A1

€51.24

Two-year warranty
Easy return within 14 days

Siemens FDM231-RP FDnet/C-NET Manual call point



The FDnet/C-NET manual call point offers a reliable and straightforward solution for fire alarm activation. With an immediate activation mechanism and a communication system via FDnet/C-NET, this button is ideal for ensuring rapid response in emergency situations. The plastic component, which can be reset by a simple key, allows intuitive operation and quick reactivation.



Two-color LED system for status and testing



Featuring a two-color LED, the FDnet/C-NET call point visually signals alarm status and test phases, enhancing monitoring clarity. The alarm indicator is easily visible even from a distance, providing enhanced safety for the environment.



Detailed technical features:

  • Manual button for FDnet/C-NET detector bus automatically addressable
  • Manual button with direct activation
  • Two-wire system for all cable types
  • Installed alarm indicator (LED)
  • Two-color LED for alarm and test
  • Direct alarm activation by pressing the plastic component
  • With the key, the switch is recharged and is ready for operation again
  • External alarm indicator (AI) 1
  • Connection terminals 0.281.5 mm2
  • Operating temperature -25+65 °C
  • Storage temperature -30+65 °C
  • Air humidity, non-condensing ?95 %
  • FDnet/C-NET communication protocol
  • Protection category IP44
  • Type A version (direct activation)



Application:

  • Suitable for indoor use only
  • For wall mounting
  • For cable entry in wall and flush mounting in well-accessible locations

Data sheet

Type:
Buttons
