Benefits:

• For supplying power to MV/LV transformer substations in accordance with CEI 0-16.
• Designed to have the recharging reserve capable of restarting theUPS for load reset
• Power Factor 0.9
• IGBT Rectifier
• Compatibility with generator set
• Microprocessor-controlled battery charging system
• Static bypass
• Intelligent slot for SNMP or Dry Contact card
• High efficiency and low operating cost
• TecnoManager UPS management software compatible with Windows, Mac OS X Unix, Linux, etc.



Features:

• Rated power 1000VA
• Active power 900W
• Power Factor 0.9
• On-Line Double Conversion Transformerless Technology (VFI-SS-111)
• Forced Cooling via Fan
• Noise level < 45 dBA at 1 m
• UPS Dimensions WxHxD 23x33x37 cm
• Weight 10 kg



Input:

• Number of phases 1F+N
• Rated voltage 208Vac/220Vac/230Vac/240Vac
• Input voltage tolerance 110-300Vac
• Rated frequency 50/60 Hz (selectable) Input frequency tolerance in On-Line mode +/- 7%.
• Input power factor 0.99




Output:

• Number of phases 1F+N
• Rated voltage 208Vac/220Vac/230Vac/240Vac (selectable)
• Voltage stability at %100 ±1% linear load (On-Line and Battery modes)
• Voltage harmonic distortion THD <2% (with linear load), <8% (with nonlinear load)
• Crest factor 5:1
• Frequency 50/60 Hz (selectable)
• Frequency stability ±0.2 Hz
• Waveform Inverter Sinusoidal
• Allowable overload 110% audible alarm only, 110-130% for 30 s, >130% for 100 ms
• Efficiency 94%, calculated in double conversion mode at 100% load according to 62040-3
• Trip Time 0 ms (On-Line)



Battery:

• Lead acid, sealed, maintenance-free
• Typical Runtime 110 min with 50W



Environmental Operating Conditions:

• Working temperature 0 to 55° C (for proper battery operation 20 to 25° C)
• Relative humidity < 95% non-condensing
• Maximum altitude 3000 m
• Degree of protection IP20
• CE certifications (Reference standards: safety IEC EN 62040-1; EMC IEC EN 62040-2; classification IEC EN 62040-3).
