Advantages:

• Supports all DVA video analysis functions of connected cameras
• Face and license plate database
• Compatible with browsers: IE/Google Chrome/Edge/Firefox/Safari
• Alarm inputs/outputs
• Remote control via Comelit CCTV APP and Comelit CCTV Manager software



Features:

• Video inputs 16 PoE (12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280x1024/960P/ 720P/960H/D1/CIF)
• Main video outputs 1 HDMI (4K) 1 VGA (1920x1080), (VGA programmable)
• Audio inputs/outputs 1 / 1
• Alarm inputs/outputs 8/4
• Video compression H.265S / H.265+ / H.265 / H.264
• Frame rate in playback/recording 30fps@8MP 20fps@12MP
• Provided hard disk capacity 2TB (10TB max)
• Additional hard disks (SATA) 1 (10TB max)



Software/Firmware Features:

• Recording methods Automatic, manual, scheduled, event
• Maximum no. of channels played simultaneously 1@12MP, 4@Full HD
• Supported protocols DDNS, DHCP, HTTP, HTTPS, SMTP, TCP/IP, ONVIF (Profile-T, Profile-S, Profile-G)
• DHCP IP assignment, manual
• Max. bandwidth (Mbps) 192
• Remote control by browser Internet Explorer, Firefox, Chrome, Safari
• Remote control from Comelit CCTV Manager software
• Remote control from mobile APP Comelit CCTV
• Simultaneously connected users 64
• Main functions Video analysis (only with dedicated cameras), Parking management function, Alarm system function
• Functions: Motion detection (zones)



Features:

• Machine power consumption (no HDD) (W) 20
• Maximum power consumption per POE port (W) 30
• POE total power (W) 150
• Maximum distance in long range mode (m) 100
• Supply voltage (VDC) 48
• Dimensions: Height (mm) 45 - Width (mm) 380 - Depth (mm) 268
• Product weight (g) 3800
• Type coating materials Metallic
• Product color Black
• Operating temperature (°C) -10 to 50
• Operating humidity (RH max) (%) 25 ÷ 90
• Type of connections/ports 1 x Ethernet 10/100/1000 Mbit/s, 2xUSB 2.0, 1xUSB 3.0, 16 x Ethernet PoE 10/100 Mbit/s
