Advantages:

• Supports all DVA video analysis functions of connected cameras
• License plate database
• Compatible with browsers: IE/Google Chrome/Edge/Firefox/Safari
• Remote control via Comelit CCTV APP and Comelit CCTV Manager software
• This NVR connects to Comelit's servers protected by AWS services



Features:

• Video inputs 4 PoE (4K/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF)
• Main video outputs 1 HDMI (4K) 1 VGA (1920x1080)
• Audio inputs/outputs 1 / 1
• Video compression H.265S / H.265+ / H.265 / H.264
• Frame rate in playback / recording 30fps@8MP
• Included hard drive capacity 1TB (10TB max)



Software/firmware features:

• Recording methods Automatic, manual, scheduled, event
• Maximum number of channels played back simultaneously 1@4K, 6@Full HD
• Supported protocols DDNS, DHCP, HTTP, HTTPS, SMTP, TCP/IP, ONVIF (Profile-T, Profile-S, Profile-G)
• DHCP IP assignment, manual
• Max. bandwidth (Mbps) 80
• Remote control from Internet Explorer, Firefox, Chrome, Safari browsers
• Remote control from Comelit CCTV Manager software
• Remote control from mobile APP Comelit CCTV
• Simultaneously connected users 64
• Main functions Video analysis (only with dedicated cameras), Parking management function, Alarm system function
• Functions: Motion detection (zones)



Hardware Features:

• Type of connections/ports 1 x Ethernet 10/100/1000 Mbit/s, 2xUSB 2.0, 4 x Ethernet PoE 10/100 Mbit/s
• Fanless



General Data:

• Machine power consumption (no HDD) (W) 10
• Maximum power consumption per POE port (W) 30
• POE total power (W) 48
• Maximum distance in long range mode (m) 100
• Supply voltage (VDC) 48
• Dimensions: Height (mm) 45 - Width (mm) 300 - Depth (mm) 249
• Product weight (g) 2700
• Type coating materials Metallic
• Product color Black
• Operating temperature (°C) -10 to 50
• Operating humidity (RH max) (%) 25 ÷ 90
• Included accessories Power supply unit, Mouse
