Product features:

• ONVIF compatible
• Video analysis functions: Cross line detection, Area intrusion detection
• H.265+ / H.265 / H.264+ / H.264 / MJPEG video compression
• Audio: built-in microphone
• IP67 waterproof die-cast aluminum enclosure
• 12VDC/ PoE IEEE802.3af power supply
• Browser compatible: IE/Google Chrome/Edge/Firefox/Safari



Features:

• 1/3" CMOS Ultra Starlight camera sensor
• Lens size fixed lens (mm) 2.8
• Effective pixels (H x V - pixels) 2592x1520
• Horizontal field of view (°) 95
• Vertical field of view (°) 53
• Diagonal field of view (°) 115.2
• Electronic shutter (s) 1/3 ÷ 1/100000
• Sensitivity 0.03 (color), 0 (black and white, IR led ON)
• Signal-to-noise ratio (dB) >50
• Video transmission Triple streaming
• Management software Comelit CCTV Manager



Software/Firmware Features:

• H.265+ / H.265 / H.264+ / H.264 / MJPEG video compression
• Frame rate 30fps
• ONVIF (Profile-S) Supported Protocols
• Special features Dual light
• Firmware update via network Yes
• Simultaneously connected users 3
• Remote viewing from Internet Explorer, Firefox, Chrome, Safari browsers
• Remote control from mobile APP Comelit CCTV



Features:

• Main functions 3D-DNR, BLC, Defog, HLC
• Motion detection (zones) Yes
• Video analysis Line crossing, area entry
• Privacy zones (no.) 4
• Wide Dynamic Range (WDR) D-WDR
• 3D-DNR Control
• White balance adjustment AWB, Indoor, Manual, Outdoor
• Automatic exposure control
• Brightness adjustment
• Camera titration




Hardware features:

• IR LED illumination distance 20m
• White LED illumination distance 20m
• Vandal-proof degree of protection IK IK10
• IP67 degree of protection
• Audio inputs/outputs 1 (microphone) / -
• LAN output type Ethernet 10/100 Mbit/s (RJ45)



General data:

• Supply voltage 12VDC
• Power consumption max (W) 5
• PoE Power Supply IEEE 802.3af Standard
• PoE power supply type, External power supply
• Dimensions: Height (mm) 74.8 - Width (mm) 73.8 - Depth (mm) 162.1
• Casing Material Type Die-cast aluminum
• Case Type Bullet
• Product color White
• Operating temperature (°C) -30 to 60
• Operating humidity (RH max) (%) 25 ÷ 95



Compatible fixing accessories:

• Junction box for attaching Next and Advance JBABA cameras.
• Wall mounting bracket for Next and Advance WMABA cameras
• Accessory for pole mounting of Next and Advance cameras Pole diameter 80 to 140mm PMAA
• Advance Next Ceiling Bracket CMABA
• Advance Next Corner Bracket AMAA
