Advantages:

• Up to 16 IP camera inputs
• H.265+/H.265/H.264+/H.264 video formats
• Decoding capability of up to 2 channels at 12 MP or 3 channels at 8 MP or 6 channels at 4 MP or 12 channels at 1080p
• Up to 160 Mbps input bandwidth
• Adopts Hikvision Acusense technology to minimize manual effort and security costs




Features:

• Face image comparison, human face capture, face image search
• Up to 16 face image libraries, with up to 20,000 face images in total (each image ? 4 MB, total capacity ? 1 GB)
• Video analysis on all channels, up to 4 MP (when advanced SVC mode is enabled, up to 8 MP) for recognition of people and vehicles to reduce false alarms
• 2-channel, 4 MP video analysis (HD network camera, H.264/H.265) for person and vehicle recognition to reduce false alarms
• Inbound Bandwidth: 160Mbps
• Outgoing Bandwidth: 160Mbps
• HDMI Output: 1 channel, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1024 x 768/ 60Hz
• VGA output: 1 channel, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Audio Output: 1 channel, RCA (linear, 1 K?)
• Two-way Audio: 1 channel, RCA (2.0 Vp-p, 1 K?, using audio input)
• Decoding Format: H.265/H.265+/H.264+/H.264
• Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Browser Compatible: IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or later version
• Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
• Capacity: Up to 10TB capacity per HDD
• Serial Interface: 2 RS-485 (half-duplex), 1 RS-232
• USB Interface: Front panel: 2 × USB 2.0; Back panel: 1 × USB 3.0
• Power Supply: 100 to 240 VAC, 50 to 60 Hz
• Power Consumption: 20 W (without hard disk)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10 to 90%
