Advantages:

• 4 MP CMOS image sensor, 1/3, low illumination, high image definition - Outputs max. 4 MP (2688 × 1520) at 30 fps
• H.265 codec, high compression rate, low bit rate
• Built-in IR LED, max. IR distance: 50 m
• ROI, SMART H.264+/H.265+, exible codec, applicable to various bandwidth and storage environments
• Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermark, applicable to various monitoring scenes
• Intelligent detection: intrusion, tripwire (supports classification and accurate detection of vehicles and people)
• Anomaly detection: motion detection, video tampering, scene change, audio detection, SD card absent, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
• Supports max. 256 G Micro SD card, built-in microphone - 12V DC/POE power supply
• IP67 protection
• SMD Plus




SMD Plus:

• With an intelligent algorithm, Smart Motion Detection technology can classify the targets that trigger motion detection and filter the motion detection alarm triggered by unaffected targets to realize an effective and accurate alarm



Intelligent H.265+ and Intelligent H.264+:

• With advanced scene-adaptive rate control algorithm, intelligent encoding technology realizes higher encoding efficiency than H.265 and H.264, provides high-quality video and reduces storage and transmission costs



Perimeter Protection:

• Using the deep learning algorithm, the perimeter protection technology can accurately recognize people and vehicles. In restricted areas (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as alarm, intrusion, rapid movement, parking detection, parking detection, and assembly detection) are largely reduced



Starlight:

• Starlight technology is mainly applied to low-light environments and can provide clear and colorful video. Even in the min. lighting environment, the technology can ensure the good image effect



WDR:

• With advanced Wide Dynamic Range (WDR) technology, the network camera provides clear details in an environment with strong brightness contrast. The light and dark area can achieve sharp video even in high brightness or backlit shadow environments




Camera:

• 1/3, 4-megapixel progressive CMOS image sensor
• Maximum resolution 2688(O)×1520(V)
• Rom 128MB
• RAM 512MB
• Scanning System Progressive
• Electronic Shutter Speed Auto/Manual 1/3 s1/100000 s
• Minimum Illumination 0.005 Lux@F1.6
• S/N Ratio > 56dB
• Illumination distance 50 m (164.0 ft)
• Illuminator on/off control Automatic/manual
• Number of illuminator 2 (IR LED)
• Pan/tilt/rotation range Pan: 0°360°; Tilt: 0°78°; Rotation: 0°360°




Lens:

• Fixed focal length
• Mounting type M12
• Focal length 2.8mm
• Maximum Aperture F1.6
• Field of view 2.8mm: Horizontal: 103°; vertical: 55°; diagonal: 122°
• Iris Type Fixed
• Close focusing distance 1.6 m (5.3 ft.)




Professional, Smart:

• Tripwire perimeter protection; intrusion (person and vehicle recognition)
• Smart Search Collaborates with Smart NVR to refine smart search, event extraction and merging to event video



Video:

• H.265 video compression; H.264; H.264H; H.264B; MJPEG (supported by secondary stream only)
• Intelligent Codec Intelligent H.265+/ Intelligent H.264+
• Video frame rate Main stream (2688 × 1520 at 125/30 fps) secondary stream (704 × 576 at 125 fps/704 × 480 at 130 fps) third stream (1280 × 720 at 125/30 fps)
• 3 stream capacity
• Resolution 4M (2688×1520); 3M (2304×1296); 1080p (1920×1080); 1.3 million (1280 × 960); 720p (1280×720); D1 (704×576/704×480);VGA (640×480); CIF (352×288/352×240)
• CBR/VBR bit rate control
• Video bitrate H.264: 3 Kbps8192 Kbps H.265: 3 Kbps8192 Kbps
• Day Night Auto(ICR)/Color/B&W
• BLC
• HLC
• WDR 120dBB White balance Auto/natural/road/outdoor/manual/custom regional
• Get control Auto/manual
• 3D DNR Noise Reduction
• Motion detection OFF/ON (4 areas, rectangular)
• Region of interest (RoI) Yes (4 areas)Intelligent lighting
• Image rotation 0°/90°/180°/270° (Supports 90°/270° with resolution 1920 × 1080 and below.)
• Privacy masking 4 areas



Audio:

• Built-in MICROPHONE
• Audio compression G.711a; G.711Mu; G726; CAA



Alarm:

• Alarm event No SD card; SD card full; SD card error; less SD card service time (supports smart card); network disconnection; IP conflict; illegal access voltage detection; security exception; motion detection; video tampering; scene change; intensity change; tripwire; intrusion; SMD



Network:

• RJ-45 (10/100 Base T)
• SDK and API
• Protocol IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP; Multicast;ICMP;IGMP;NFS;PP-PoE;802.1x;SNMP
• Scene Self-adaptive



Certifications:

• CE-LVD: EN62368-1
• CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
• FCC: 47 CFR FCC Part 15, Subpart B
• UL/CUL: UL60950-1 CAN/CSA C22.2 N.60950-1-07



General:

• 12 V DC/PoE (802.3af) power supply.
• Power consumption <7.7 W
• Operating conditions -40°C to +60°C (-40°F to +140°F)/minus 95%.
• Storage conditions -40°C to +60°C (-40°F to +140°F)
• Degree of protection IP67
• Enclosure: Inner core: metal. Cover: metal. Decorative ring: plastic
• Dimensions: 99.1 mm × ÿ121.9 mm (3.9" × ÿ4.8")
• Net weight 480g (1.05 pounds)
